Piping Reference Screenshots
Piping Reference Description
This application is dimension of piping and accessories. It has many accessories in the app such as pipe size, pipe clamp, fitting, flange and pipe hanger. This app have boths metric and us unit. It will auto change unit when user select pipe standard NPS (in) or DN (mm).Pipe Detail
- Carbon Steel Pipe Size
- Carbon Steel Pipe Standard
- Carbon Steel Pipe Strength
- Stainless Steel Pipe Size
- Stainless Steel Pipe Standard
- Stainless Steel Pipe Strength
Pipe Clamp
- U-Bolt
- Hold Down Pipe Clamp
- 2 Bolt Pipe Clamp
- 3 Bolt Pipe Clamp (Carbon and Alloy Steel)
- Riser Clamp
Fitting Detail
- 180 Return
- 45 Elbow
- 90 Elbow
- Cap
- Concentric Reducer
- Coupling
- Cross
- Eccentric Reducer
- Half Coupling
- Hexagonal Head Bushing
- Hexagonal Head Plug
- Hexagonal Nipple
- Male-Female Reducer
- Reducer Insert
- Reducing Coupling
- Reducing Hexagonal Nipple
- Reducing Outlet Tee
- Square Head Plug
- Straight Tee
- Union
- Welding Boss
Flange Detail
- Flange Blind
- Flange Lap Joint
- Flange Slip-On Welding
- Flange Socket Welding
- Flange Threaded
- Flange Welding Neck
Pipe Hanger
- Lug
- Beam Welding
- invert Beam Welding
- Hanger Rod
- Rod Coupling
- Clevis Pin
Features of Piping Reference 2.9.3
V.2.9- Add gasket dimensions
